Wear Resistant Alumina Ceramic Tube 95% Ceramic Lined Composite Drainage Pipe

MOQ: 2 piece
Price: Negotiation
Standard Packaging: Use the export carton which is secure against breakage on the MDF pallet.
Delivery Period: To be negotiated
Payment Method: L/C ，T/T, Western Union
Supply Capacity: 300000 Piece/Pieces per Month
Detail Information
Product Description
Detail Information
Place of Origin
Jiangsu, China
Brand Name
LJ Ceramic
Certification
ISO9001:2008/ROHS
Model Number
Alumina Ceramic Tube
Name:
Alumina Ceramic Tube
Type:
Ceramic Tubes
Application:
Industrial Ceramic
Size:
Size Customized
Feature:
High Temperature Resistance
Shape:
Customized
Minimum Order Quantity:
2 piece
Price:
Negotiation
Packaging Details:
Use the export carton which is secure against breakage on the MDF pallet.
Delivery Time:
To be negotiated
Payment Terms:
L/C ，T/T, Western Union
Supply Ability:
300000 Piece/Pieces per Month
Highlight:

Wear Resistant alumina ceramic tube

,

alumina ceramic tube 95%

,

Ceramic Lined Composite drainage pipe

Product Description

Alumina Ceramic Wear-Resistant Pipe Drainage Pipe Ceramic Lined Composite Pipe

The hardness of wear-resistant ceramics is higher, second only to diamond, far exceeding the wear-resistant steel and stainless steel wear resistance, also known as special corundum ceramics. It has stable chemical properties, in high temperature environment, will not occur deformation or damage, so it also has high temperature resistance.



Alumina Ceramic Properties


1. High voltage resistance

2. Excellent insulation performance

3. High corrosion resistance

4. High mechanical strength and hardness

5. Extremly abrasion resistance performance

6. High temperature up to 1600ºC

7. Wide scope of application


Alumina Ceramic Properties



Alumina Ceramic Properties 95%Al2O3 99%Al2O3 99.5%Al2O3
Item Unit Typical Values
Physical Properties
Color   White Ivory yellow
Density g/cm3 >3.6 3.89 3.96
Alumina Content % 95% 99% 99.50%
Gas permeability   0 0 0
Water Absorption   0 0 0
Mechanical Properties
MONS' Hardness Grade 9 9 9
Rockwell Hardness HRA ≥85 ≥89 ≥89
Vickers Hardness (Hv50) Gpa(Kg/mm²) 15.7(1600) 15.7(1600) 15.7(1600)
Flexural Strength(20°C) psiX103 358 550 550
Compressive Strength(20°C) psiX103 2068(300) 2600(377) 2600(377)
Modulus of Elasticity Gpa 275
Fracture Toughness(20°C) Mpa.m3/2 4.3 5.6 6
Thermal Properties
Thermal Conductivity(20°C) W(m.K) 16 30 30.4
Thermal Expansion(25-1000°C) 1X10-6/℃ 7.6 7.9 8.2
Maximum Use Temperature °C 1450 1600 1650
Thermal shock resistance °C 250 200 200
Electronic Properties
Volume resistivity(100°C) Ohm/cm2 >1013 >1014 >1014
Dielectric breakdown strength KV/mm 8.7(220) 8.7(220) 8.7(220)
Dielectric Constant Er 9 9.7 9.7
Dielectric constant (100MHz) Er 9.5



Wear Resistant Alumina Ceramic Tube 95% Ceramic Lined Composite Drainage Pipe 0Wear Resistant Alumina Ceramic Tube 95% Ceramic Lined Composite Drainage Pipe 1Wear Resistant Alumina Ceramic Tube 95% Ceramic Lined Composite Drainage Pipe 2

Wear Resistant Alumina Ceramic Tube 95% Ceramic Lined Composite Drainage Pipe 3



Purchase process



Wear Resistant Alumina Ceramic Tube 95% Ceramic Lined Composite Drainage Pipe 4

Wear Resistant Alumina Ceramic Tube 95% Ceramic Lined Composite Drainage Pipe 5
